Simpson Strong-Tie LSSR2.37Z LSSR® Light Field-Adjustable Rafter Hanger for 2-5/16 in. Engineered Wood
Hangers

Simpson Strong-Tie LSSR2.37Z LSSR® Light Field-Adjustable Rafter Hanger for 2-5/16 in. Engineered Wood

SKU: LSSR2.37Z
📦 Available to Order — Add to Quote
Madison Township Lumber • Matawan, NJ
(732) 566-5555
Share

Product Description

The patent-pending LSSR® light slopeable/skewable rafter hanger is the next generation of a field-adjustable rafter hanger. One of its key features is that it can be installed after all of the rafters have been tacked into place. A versatile hanger, it is field adjustable for skew up to 45° and features an innovative hinged swivel seat to adjust for up to a 45° slope.

Available Sizes & Options

SKUProductStatus
LSSR2.37ZSimpson Strong-Tie LSSR2.37Z LSSR® Light Field-Adjustable Rafter Hanger for 2-5/16 in. Engineered Wood CurrentAvailable
IUS1811188Simpson Strong-Tie 1 3/4 x 11-7/8 I Joist HangerAvailable
HUS18110Simpson Strong-Tie 1 3/4 x 9 1/2 Sloped Face Mount HangerAvailable
SUR18111Simpson Strong-Tie 1-3/4 x 11-7/8 Skew 45 R I-beam/lvlAvailable
IUS18195Simpson Strong-Tie 1-3/4 x 9-1/2 Side Mount SingAvailable
1212HLSimpson Strong-Tie 1212HL HL 12 in. x 12 in. 7-Gauge Galvanized Heavy L StrapAvailable
1212HLHDGSimpson Strong-Tie 1212HLHDG HL 12 in. x 12 in. 7-Gauge Hot-Dip Galvanized Heavy L StrapAvailable
1212HLPCSimpson Strong-Tie 1212HLPC HLPC 12 in. x 12 in. 7-Gauge Black Powder-Coated Ornamental L StrapAvailable
1212HTSimpson Strong-Tie 1212HT HT 12 in. x 12 in. 7-Gauge Galvanized Heavy T StrapAvailable
1212HTHDGSimpson Strong-Tie 1212HTHDG HT 12 in. x 12 in. 7-Gauge Hot-Dip Galvanized Heavy T StrapAvailable
1212HTPCSimpson Strong-Tie 1212HTPC HTPC 12 in. x 12 in. 7-Gauge Black Powder-Coated Ornamental T StrapAvailable
1212LSimpson Strong-Tie 1212L 12 in. x 12 in. 14-Gauge Galvanized L StrapAvailable
1212L-RSimpson Strong-Tie 1212L-R 12 in. x 12 in. 14-Gauge Galvanized L StrapAvailable
1212TSimpson Strong-Tie 1212T 12 in. x 12 in. 14-Gauge Galvanized T StrapAvailable
1212T-RSimpson Strong-Tie 1212T-R 12 in. x 12 in. 14-Gauge Galvanized T StrapAvailable
128TSimpson Strong-Tie 128T 12 in. x 8 in. 14-Gauge Galvanized T StrapAvailable
128T-RSimpson Strong-Tie 128T-R 12 in. x 8 in. 14-Gauge Galvanized T StrapAvailable
1616HTSimpson Strong-Tie 1616HT HT 16 in. x 16 in. 7-Gauge Galvanized Heavy T StrapAvailable
1616HTHDGSimpson Strong-Tie 1616HTHDG HT 16 in. x 16 in. 7-Gauge Hot-Dip Galvanized Heavy T StrapAvailable
1616HTPCSimpson Strong-Tie 1616HTPC HTPC 16 in. x 16 in. 7-Gauge Black Powder-Coated Ornamental T StrapAvailable
1616HTQSimpson Strong-Tie 1616HTQ HTQ 16 in. x 16 in. 7-Gauge Hot-Dip Galvanized Heavy T StrapAvailable

Product Details

Key Features

  • Makes it possible to install after the rafters are already in place
  • Flange design allows for easy skew (left or right) adjustment, from 0° to 45°
  • Swivel seat adjusts easily from 0° to 45° up or down

Material

  • See table

Finish

  • ZMAX® coating

Installation

  • Installation Guide
  • Use all specified fasteners; see General Notes
  • Limit on-center spacing of rafters and joists with LSSR210-2Z and LSSR410Z to 14" o.c., minimum; for the LSSR1.81Z, LSSR2.1Z, LSSR2.37Z and LSSR2.56Z, limit the on-center spacing to 11" o.c., minimum
  • For a common rafter:
    • Slide hanger into position; adjust seat and install seat nails
    • Make sure side stirrups are snug close to the joist, bend lines are plumb
    • Install a face nail on each side to hold in place
    • Install all round and obround holes on the header and joist
  • For jack rafters:
    • Fold acute side forward
    • Slide hanger into position; adjust seat and install seat nails
    • Make sure hanger is snug close to the joist, bend line is plumb
    • Install obround nails on acute side, both header and joist
    • Make sure hanger is snug close to the joist and header; bend line is plumb
    • Install joist nails on obtuse side
    • Bend obtuse side flange back so that header flange is flush against header
    • Install header nails
  • Web stiffeners required for I-joist applications
